Inline PCBA Automatic Optical Inspection machine Aoi pcb Inspector for SMT/DIP Production Line Production Overview: High precision: multiple software analysis methods, multiple application modes, high-precision motion system;High efficiency: one maintenance workstation confirms the detection data of multiple online machines, realizing fully automated process control.

Machine Characteristics: Adopt cast iron Y crossbeam to better ensure the accuracy and stability of the machine. The Y-axis adopts double servo synchronous drive, which reduces deformation and improves positioning accuracy.

Conveyor system that can automatically adjust the conveyor width according to the program setting. Equipped Z-axis lifting to cope with PCB bending adjustment and clear imaging of the top of high components. Equipped with a support structure to allow the PCB to be clamped after being levelled with the track.

The transport motor adopts double closed-loop stepping motors to work synchronously, and automatically centers and stops the PCB according to the PCB length, instead of mechanical blocking stops to reduce the impact on the PCB. The transport belt adopts timing belt, which can easily handle 5 KG heavy PCB .

The main camera is standard with a 12M P high-speed camera and 4 projectors (8 projectors optional) . A n optional side camera is available to improve component identification and to identify poor soldering at the bottom of the components . Camera is standard with bar code recognition function .

Standard with SMEMA interface . Technical Parameters: P ower S upply 200-240VAC 50/60.

Hz Power Normal 1.8KW, Maximum 5KW Air Supply 0.5MPa 25 L/min Dimension L 1300 * W 1438 * H1657 mm Weight 1500kg Conveyor Front fixed, single lane, 3-stage stop (1-stage conveyor for PCB length larger than 330 mm) Operating system Windows 10 Conveyor Direction Left to right, right to left, left to left, right to right (programmable) PCB size L 50 * W 50 ~ L 510 * W 510 mm Thickness Max 6mm Minimum Component Metric 0201 (with optional 7 um lens) / Metric 0603 (Imperial 0201) (with 12 um lens) Main Camera 12MP _ Main lens Standard with 12um (7um optional) Side camera 12MP ( optional) fO _ 48.6*36.4mm 3D projectors 4 (8 optional) Maximum 3D detectable component Standard 18 mm (Z-axis head lift up to 35 mm) Maximum component height Top 50mm, Bottom 20mm Maximum PCB bend compensation ±4mm Light sour
