Long-Distance Overland Belt Conveyors BASIC INTRODUCTION Long distance overland flat turn belt conveyor is a continuous conveying equipment that uses steel rope core conveyor belts as traction components.

Its ultra long conveying distance and super large conveying capacity, as well as the multi-point horizontal turning curve conveying method, can maximize the satisfaction of high yield and efficient material transportation in working faces.It is a key equipment for comprehensive mining and production systems to achieve in uipment vigorously promoted and used by countries around the world.

PRODUCT FEATURES The long distance overland conveyor is a special type of belt conveyor that achieves long-distance and curved transportation. It can perform flat turns, as well as vertical convex and concave turns, forming a spatial curve.

This is achieved by lifting the inner curve of the conveyor belt, adjusting the deflection angle of the idler, and using deep groove idler groups to generate an outward centrifugal thrust during operation to overcome the centripetal force of the conveyor caused by turning, ensuring the smooth operation of the belt during turns.

By using a curved track, it can avoid obstacles or unfavorable terrain, and achieve the goal of simplying the system and saving investment by reducing or eliminating the need for intermediate transfer stations.

APPLICATION INDUSTRIES Long distance overland flat turn belt conveyor is widely used in various industries such as mining, coal, power plants, ports, docks, building materials, metallurgy, cement, chemistry, steel, etc. ADVANTAGES 1. continuous long-distance transportation, stable and reliable work 2.

large conveying capacity, high production efficiency 3. low noise, low pollution, low energy consumption 4. simple structure and low operating costs SK TYPICAL LONG DISTANCE BELT CONVEYOR E FOR WEIFANG PORT COMPANY INTRODUCTION Established in 1955, Shandong Mining Machinery Group Co., Ltd.

(the "Company" ) owns 21 holding companies including Shandong Mining Machinery Equipment Manufacturing Co., Ltd, and was listed on Shenzhen Stock Exchange (stock code: SZ002526) in December 17, 2010.

By the end of 2022, the Company owns total assets of RMB 4.3 billion, floorage of more than 2,000 acres (approxima As one of the key manufacturers of in is in the leading position in terms of scale, market share and product technical level.

We have standardized and serialized various types of belt conveyors (with belt width range 600-2400), such as General series, DTII, DTI I (A) series, Overland Conveyor, Inclined Conveyor with Large Inclination Angle, Turning Conveyor, Bidirectional Conveyor, Pipe Conveyor, etc.

The bulk conveyors now register total installed power of 8,000KW, conveying capacity of 11,500t/h, inclination from -28 to + 33 degree, belt width of 2,400mm, maximum speed of 6.3 m/s, and maximum conveying distance per unit of 12.6 km.

The company has complete research and development, design, test, detection, and measurement capabilities, and has complete manufacturing capabilities for in ent, automatic spraying and assembly.

It has qualifications for specialized contracting of foundation engineering and steel structure engineering, general contracting of electromechanical engineering construction, in capability of EPC, BOT and BT operation and maintenance of in The Technology R&D Center has more than 100 professional technicians and
