German Tech Precision Make Sturdy Safe Efficient | RFQ Sourcing Details

. Overview Certifications Detailed Photos Our Advantages FAQ Overview . Model NO.

KB30-L3 Cab Location Adjustable Type Diesel Forklift Power Diesel Engine Load Capacity 1T - 5T Fuel Diesel Load center 500mm Lift height 3000~5000mm Condition New Rated Load Capacity 3000kg Standard Maximum Lifting Height 3000mm Overall Length(Forks on Ground) Approx. mm Overall Width(Incding Forks) Approx.

mm Overall Height(with Overhead Guard) Approx. mm Minimum Turning Radius Approx. mm Wheeibase Approx.

mm Maximum Lifting Speed(No-Load) 6.0-7.0m/Min Maximum Travel Speed(Full-Load) 16-18km/H Maximum Gradability(Full-Load) ≥20% Engine Rated Power 30-40kw( rpm) Fuel Tank Capacity 60-80L Overaall Operting Weight kg Front Axle Load(Fuel-Load) kg Tire Specifications Front-Solid Tire 28*9-15 Transport Package Nude Packing Specification 4t Trademark BAOLI Origin Putian City, Fujian Province HS Code Production Capacity 200 Certifications Detailed Photos Our Advantages 1.

Strong Environmental Tolerance It can adapt to various extreme climates such as high temperature, low temperature and high humidity, and maintain stable operation even in severe weather conditions. 2.

High Modification Potential It supports the installation of various attachments such as side shifters, clamps and pushers, which can meet the handling needs of different types of goods and expand the operation scope. 3.

High Resale Value The core mechanical structure is durable with slow depreciation, and it can maintain a high market value when resold, reducing long-term investment costs. FAQ 1. Q: What causes black smoke or blue smoke during the operation of an internal combustion forklift?

A: Black smoke is mostly due to insufficient fuel combustion, commonly caused by a clogged air filter, faulty fuel injectors, or overloading operations. Blue smoke is highly likely a sign of engine oil burning, which requires inspecting whether components like piston rings and valve oil seals are worn. 2.

Q: What are the core daily inspection items for an internal combustion counterbalance forklift?

A: Check the fuel/LPG storage capacity, engine oil and hydraulic oil levels;inspect the tire pressure and wear condition, and the brake pedal stroke;check whether the forks have deformation or cracks and whether the lights and horn work normally;conduct a no-load test run to confirm that the steering, lifting and braking functions are free of abnormalities.

3. Q: Can internal combustion forklifts operate for long periods in enclosed indoor spaces? A: No. Internal combustion forklifts emit harmful exhaust gases such as carbon monoxide and nitrogen oxides during operation, which are prone to accumulation in enclosed spaces and endanger the health of operators.

Only LPG models can be used for short periods in well-ventilated indoor areas, and exhaust gas emission devices must be installed. 4. Q: What safety regulations must be followed when operating an internal combustion counterbalance forklift on ramps?

A: Drive forward when ascending a ramp, keep the forks low and tilted backward to prevent goods from slipping;drive in reverse when descending a ramp and never coast in neutral gear.

Turning and parking on ramps are prohibited;if temporary parking is necessary, secure the wheels with chocks and fully engage the handbrake. 5. Q: What are the wearing parts of an internal combustion forklift and what is the general warranty period?

A: Common wearing parts include tires, brake pads, various filters, transmission belts, etc. The warranty period for these parts is usually 3 months or 500 operating hours, subject to the product manual and the manufacturer's warranty terms. 6.

Q: How to conduct initial troubleshooting when an internal combustion forklift has difficulty starting?

A: First, check whether the fuel storage is sufficient and the battery power is normal;then clean the air filter to rule out startup failures caused by intake blockage;if the forklift still fails to start, it is necessary to inspect ignition and fuel supply components such as spark plugs and fuel injectors.
