Full Auto Batch Production Line Die Cutter Rotato | RFQ Sourcing Details

1. Module belt conveyor Short Description Auto Module Conveyor System is high efficient downstream and processing system for modern corrugated cardboard and carton box factory.

Through the layout of the whole plant, a reasonable plan is designed to realize automatic cardboard conveying and reduce manpower and material resources Brand GOJON Product origin Qingdao,China Size Customized Delivery time 30days Supply capacity 1000sets/month Product Catagary: function High efficient downstream processing system for modern corrugated cardboard production line and printer line.

Process Instruction After the stacker of printer die cutter, it needs the logistics system to accomplish the high or middle speed production line.

Firstly, after the paper sheets output from the stacker of die cutter, it transports to the Rotator, and rotate +/- 90 degree, then transport to Breaker to Split small piece.

Secondly, through the long drive roller, and stack by worker, then discharge & deliver through XY direction Combined Conveyor and connect next station. For the load former line, all pallets were feeded one by one automatically.

Layout Of Auto Breaker & Rotator & Load Former Line Main Machine & Equipment List a)Breaker main body Breaker 1.One way blanks breaker 2.The machine can do multi-products in one sheet in single direction, like blanks layout as 1x2, 1x3, 1x4, 1x5 and etc.

Two breakers work together for blanks layout as 2x2, 2x3, 2x4, 2x,5, 3x3, 3x4, 3x5 and etc. 3. It can be used inline with die cutter, folder gluer.

Technical Data Maximum sheet size 1650×1200mm Minimum sheet size 430×360mm Maximum height of batch 300mm Minimum height of batch 50mm Maximum speed 9 times per min Sheet Transfer height 800 mm Machine size (L x W x H) 2650×2800×2100 mm Total power consumption 5kW Power supply 380V, 3-ph, 50hz Net weight 4 tons b)Sheet Batch Rotator 1.

To complete the rotation of the sheets by 90 degrees, Go straight, Precise positioning rotation, etc. 2.Electric control going up & down, and rotation in high precision. 3. After the elevation, the motor drives the divider to rotate 90 degrees and then descend.

The platform operation uses frequency converter to adjust speed. PLC choose Taiwan FATEK, Frequency converter and Photoelectric both choose Japan Panasonic, Motor choose Taiwan brand, etc. Technical Parameter Machine model DX 2000 Maxi. Sheet size 2400 x 1600mm Mini. Shee
